FDG Seismic Vinylester Chemical Injection Anchor Adhesive – H200+FC

FDG H200+FC is a top-performance ‘new generation polymer’ anchoring system with very low VOC content offering very high performance in both cracked & uncracked concrete, along with a very good performance under seismic conditions (C1 & C2). FDG H200+FC  is one of the most versatile anchoring systems in the market.

FDG H200+FC has “fast cure” properties and mixes blue and fades to grey indicating the open working time.

Features and Benefits:

  • Blue to grey colour change technology
  • Anchors may be placed close to free edges
  • Suitable for dry, wet & flooded holes
  • Reduced drilling diameters i.e. M20 only requires a 22mm hole and M24 requires only a 26mm hole making it an economical injection system
  • Variable embedment depths
  • Available in 300ml single piston foil pack cartridges
  • Ratio of 10:1.
C1 C2 Seismic Screw Bolt Anchors
C1 C2 Seismic Screw Bolt Anchors

Typical Applications:

  • Structural applications in cracked and uncracked concrete
  •  Applications where higher seismic resistance is required (C1 & C2)
  • Reinforcing & starter bars
  • Suspended ventilation systems
  • Safety barriers
  • Machinery & heavy machinery
  • Racking
  • Rolling cranes

Engineering Data


(Includes ETA Approval)

Threaded rod

(Includes ETA Approval)

Factory Certificates

ETA 23/0564 & ETA 23/0565

Safety Data Sheets

Date of compilation: 09/05/2023


  • ETA according to EAD 33049-00-0601 (Option 1: Cracked & Uncracked Concrete)
  • Seismic C1 & C2
  • ETA according to EAD 330087-00-0601 (TR023: Rebar Connections)
  • 100 years working life
  • NSF/ANSI 61 (Potable Water Contact)
