FDG Seismic Epoxy Chemical Injection Anchor Adhesive – E600+

FDG E600+ is a top-performance two-component 3:1 ratio pure epoxy bonded anchoring system for use in cracked and uncracked concrete under normal as well as very demanding seismic conditions (seismic categories C1 & C2). Designed for starter bar and post installed rebar connection applications, E600+ offers a very high load-bearing capacity. The system can be installed in percussive and diamond drilled dry, wet or flooded holes.

This 100% epoxy resin has been formulated with no Phenol, N-Methyl Pyrrolidone, Bisphenol A and Phtalates or VOCs. It exhibits minimal shrinkage, which makes it ideal for use with oversized holes, while extended gel time allows convenient use in deep holes and high ambient temperatures.

E600+ has been extensively tested at leading test facilities and has a broad range of approvals, including ETA option 1 with best C1 & C2 seismic, ETA According to TR023, LEED tested for VOC, WRAS (potable water) approval.

E600+ is available in 585ml (side-by-side) cartridges.

Features and Benefits:

• Installations in dry, wet and flooded holes even in cracked concrete without reduction in the performance. Gel and cure times remain unchanged in damp or flooded holes
• Extremely high load capacity
• Overhead applications possible
• Fixings close to free edges, stress free anchoring system
• Excellent fire resistance F240 for post-installed rebar connections
• Extended gel/open time

Approvals:

• ETA according to EAD 33049-00-0601 (Option 1: Cracked & Uncracked Concrete)
• Seismic C1 & C2
• ETA according to EAD 330087-00-0601 (TR023: Rebar Connections)
• 100 years working life
• Fire Resistance report F240 (post installed rebar connections)
• ICC-ES According to AC308 (Pending)
• A+ French VOC (Emissions Class)
• LEED Tested
• WRAS Material Approval (Potable Water Contact)
