C1 C2 Certified Seismic Screw Bolts

FDG carries a full range of C1 C2 Certified Seismic Screw Bolts so you can be sure you comply with the New Zealand Building Code. Full testing results and compliance certification is available to ensure ease of compliance and technical submission. View our full range of Seismic Anchors here.

Features and Benefits:
  • C1 C2 Seismic Screw Bolt Anchors with ETA Approval
  • Time-efficient installation through streamlined procedure – simply drill and drive
  • Completely removable with possibility of reuse
  • Unique design with patented threadform ensures high performance for relatively small hole diameter
  • Non-expansion functioning ensures low risk of damage to base material and makes R-LX ideal for installation near edges and adjacent anchors
  • Special zinc flake corrosion-resistant coating
  • High performance in both uncracked and cracked concrete
  • Different head types for any application
  • Oversize head for fixtures with elongated holes
C1 C2 Seismic Screw Bolt Anchors
C1 C2 Seismic Screw Bolt Anchors

Download Product Specification Document

This document includes all relevant product information such as:

Installation Data
Mechanical Properties
Basic Performance Data
Design Performance Data
Product Commercial Data

Download ETA Approval Document

This document was issued by the Technical and Test Institute for Construction – Prague, and contains information such as:

Technical description of the product
Specification of the intended use
Performance of the product

Applications

• Through-fixing

• Temporary anchorages

• Formwork support systems

• Balustrading & handrails

• Fencing & gates manufacturing and installation

• Racking systems

• Public seating

• Scaffolding

Base material


Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60
Non-cracked concrete C20/25-C50/60

Reinforced concrete
Reinforced concrete

Unreinforced concrete
Unreinforced concrete

C1 C2 Seismic Screw Bolt Anchors
C1 C2 Seismic Screw Bolt Anchors

Product information

Size Product Code FDG Product Code Anchor Fixture Approval type
Diameter Length Max. thickness tfix for: Hole diameter
d L hnom,red hnom,std df
[mm] [mm] [mm] [mm] [mm]
5 R-LX-05X050-HF-ZF   6.3 50 7 7
R-LX-05X075-HF-ZF   6.3 75 32 7
6 R-LX-06X050-HF-ZF MXB6X50G-S 7.5 50 7 9 ETA / Fire
R-LX-06X075-HF-ZF MXB6X75G-S 7.5 75 32 20 9 ETA / Fire
R-LX-06X100-HF-ZF MXB6X100G-S 7.5 100 57 45 9 ETA / Fire
R-LX-06X130-HF-ZF   7.5 130 87 75 9
R-LX-06X150-HF-ZF   7.5 150 107 95 9
8 R-LX-08X060-HF-ZF MXB8X60G-S 10 60 10 12 ETA / Fire
R-LX-08X075-HF-ZF MXB8X75G-S 10 75 25 5 12 ETA / C1 & C2 / Fire
R-LX-08X090-HF-ZF MXB8X90G-S 10 90 40 20 12 ETA / C1 & C2 / Fire
R-LX-08X100-HF-ZF MXB8X100G-S 10 100 50 30 12 ETA / C1 & C2 / Fire
R-LX-08X130-HF-ZF   10 130 80 60 12
R-LX-08X150-HF-ZF   10 150 100 80 12
10 R-LX-10X065-HF-ZF MXB10X65G-S 12.5 65 10 14 ETA / Fire
R-LX-10X075-HF-ZF MXB10X75G-S 12.5 75 20 14 ETA / Fire
R-LX-10X085-HF-ZF MXB10X85G-S 12.5 85 30 14 ETA / C1 & C2 / Fire
R-LX-10X100-HF-ZF MXB10X100G-S 12.5 100 45 15 14 ETA / C1 & C2 / Fire
R-LX-10X120-HF-ZF MXB10X120G-S 12.5 120 65 35 14 ETA / C1 & C2 / Fire
R-LX-10X140-HF-ZF MXB10X140G-S 12.5 140 85 55 14 ETA / C1 & C2 / Fire
12 R-LX-12X075-HF-ZF MXB12X75G-S 14.9 75 15 16 ETA / Fire
R-LX-12X100-HF-ZF MXB12X100G-S 14.9 100 40 16 ETA / Fire
R-LX-12X130-HF-ZF MXB12X130G-S 14.9 130 70 30 16 ETA / Fire
R-LX-12X150-HF-ZF MXB12X150G-S 14.9 150 90 50 16 ETA / Fire
14 R-LX-14X080-HF-ZF MXB14X80G-S 17 80 5 18 ETA / Fire
R-LX-14X105-HF-ZF MXB14X105G-S 17 105 30 18 ETA / Fire
R-LX-14X115-HF-ZF MXB14X115G-S 17 115 40 18 ETA / C1 & C2 / Fire
R-LX-14X135-HF-ZF MXB14X135G-S 17 135 60 15 18 ETA / C1 & C2 / Fire
